Table A-10. Replaceable Parts List (Cont'd)
Reference Designator Agilent Part
Number
Q'ty Description Model Mfr. P/N Mfr.
Code
CR21,22,23,24,25,
26,27,28,29,30
1901-0033 10 DIODE-GEN PRP 180V 200MA DO-35 ALL 1N645 27014
VR1,2,3 1902-0579 3 DIODE-ZNR 5.1V 5% PD=1W IR=10UA ALL 1N4733APL 04713
RT1,2 0837-0261 2 DIODE-VARISTOR ALL V275LA20A 34371
C67 0160-0263 1 CAP-FXD 0.22uF +-20% 50V CER ALL
MAGNETIC DEVICE
T1 9100-5068 1 TRANSFORMER-POWER 14 28480
T1 9100-5069 1 TRANSFORMER-POWER 15 28480
T1 NO P/N 1 TRANSFORMER-POWER 16 28480
T1 9100-5070 1 TRANSFORMER-POWER 17 28480
T2,3 9100-4969 2 TRANSFORMER-PULSE; PRI IND:5MH 14,15 28480
L1 9170-0894 1 CORE-SHIELDING BEAD ALL 28480
MISCELLANEOUS
J1 1252-4159 1 CONNECTOR-POST TYPE 2.5-PIN-SPCG 11-CO-
NT
ALL 28480
TP1-16 0360-2359 16 TERMINAL-TEST POINT .230IN ABOVE ALL 28480
S1,2,3,4 3101-3237 4 SWITCH-SL SPDT SUBMIN 6A 250VAC ALL 28480
S5 3101-3238 1 SWITCH-SL DPDT SUBMIN 6A 250VAC ALL 28480
S6 3101-1914 1 SWITCH-SL 2-DPDT STD 1.5A 250VAC PC ALL 28480
S7 3101-3115 1 SWITCH-PB MOM .5A 250VAC ALL 28480
S8 3101-3083 1 SWITCH-PB DPSTALTNG 6A 250VAC ALL 28480
0360-2548 3 TERMINAL BLOCK ALL 28480
0360-2545 1 TERMINAL BLOCK ALL 28480
0360-2546 9 TERMINAL BLOCK ALL 28480
0360-2547 1 TERMINAL BLOCK ALL 28480
A-18
