Agilent Technologies E3614A User Manual

Table A-11. Component Value
Component Model
E3614A E3615A E3616A E3617A
C2 1000UF 25V +-20% AL-ELECTLT 470UF 50V +-20% AL-ELECTLT 330UF 50V +-20% AL-ELECTLT 220UF 100V +-20% AL-ELECTLT
C7,8 39000UF 25V +-20% AL-ELECTLT 12000UF 63V +-20% AL-ELECTLT 5600UF 100V +-20% AL-ELECTLT 2700UF 160V +-20% AL-ELECTLT
C11,16,17,25,26 0.01UF 100V +-10% CER X7R 0.01UF 100V +-10% CER X7R
C12 0.1UF 50V +-10% CER X7R 0.1UF 50V +-10% CER X7R
C18,21,24,27 0.1UF 630V +-10% POLYE-FL 0.1UF 630V +-10% POLYE-FL
C19,22 1000PF 100V +-5% COG 1000PF 100V +-5% COG
C20,23 1UF 50V +-20% AL-ELECTLT 1UF 50V +-20% AL-ELECTLT
C29 0.01UF 100V +-10% CER X7R 0.01UF 100V +-10% CER X7R 0.047UF 100V +-10% POLYP-MET 0.047UF 100V +-10% POLYP-MET
C61 1UF +-10% 250V POLYP-MET 1UF +-10% 250V POLYP-MET
C62 470PF +-5% 100V CER COG 470PF +-5% 100V CER COG
C63,64,65,66 0.012UF +-10% 200V PE-FL
R1,2 0.1 +-1% 5W 0.2 +-1% 5W 0.6 +-5% 5W 1.78 +-1% 5W
R8,9 1K 1% .125W 1K 1% .125W 1K +-5% 1W 1K +-5% 1W
R11 2K +-5% 3W 5K +-5% 3W 27k +-5% 2W 45K +-5% 2W
R12 1K +-1% .125W 1K +-1% .125W
R13 68.1K +-1% .125W 68.1K +-1% .125W
R14,48,52 19.6K +-1% .125W 19.6K +-1% .125W
R15 10K +-1% .125W 10K +-1% .125W
R16 100K +-1% .125W 100K +-1% .125W
R36 7.32K +-1% .125W 6.81K +-1% .125W 8.25K +-1% .125W 9.53K +-1% .125W
R39 7.5K +-1% .125W 7.15K +-1% .125W 8.66K +-1% .125W 10K +-1% .125W
R40 2.43K +-1% .125W 3.09K +-1% .125W 5.23K +-1% .125W 6.81K +-1% .125W
R41 8.06K +-1% .125W 33.2K +-1% .125W 66.5K +-1% .125W 121K +-1% .125W
R42,44,54,56 10 +-1% .125W 10 +-1% .125W 147 +-1% .125W 147 +-1% .125W
R43,55 100 +-1% .125W 100 +-1% .125W 1K +-1% .125W 1K +-1% .125W
R45,57 100 +-1% .125W 100 +-1% .125W
R46,53 10 +-1% .25W 10 +-1% .25W
R47,50 499 +-1% .125W 499 +-1% .125W
R49,51 1.96K +-1% .125W 1.96K +-1% .125W
R58 0.2 +-1% 10W 0.2 +-1% 10W 0.6 +-1% 10W 1.78 +-1% 5W
R59 0.2 +-1% 10W 1.78 +-1% 5W
R60 390 +-5% 3W 1K +-5% 3W 1.52K +-5% 3W 2.6K +-5% 3W
R62 42.2K +-1% .125W 105K +-1% .125W 475K +-1% .125W 825K +-1% .125W
R70 178K +-1% .125W 383K +-1% .125W 23.7K +-1% .125W 100K +-1% .125W
R72 13.3K +-1% .125W 6.19K +-1% .125W 51.1K +-1% .125W 26.1K +-1% .125W
R74,75 12.1K +-1% .125W 12.1K +-1% .125W 20.5 +-1% .125W 17.8K +-1% .125W
R77 21.5 +-1% .125W 21.5 +-1% .125W 56.2 +-1% .125W 56.2 +-1% .125W
R79 147K +-1% .125W 422K +-1% .125W 681K +-1% .125W 1M +-1% .125W
R82 26.1K +-1% .125W 26.1K +-1% .125W 68.1K +-1% .125W 68.1K +-1% .125W
R98 261K +-1% .125W 100K +-1% .125W 68.1K +-1% .125W 31.6K +-1% .125W
R115 75K +-1% .125W 82.5K +-1% .125W 75K +-1% .125W 68.1K +-1% .125W
R116 28K +-1% .125W 38.3K +-1% .125W 38.3K +-1% .125W 35.7K +-1% .125W
R124 1 +-1% .125W 1 +-1% .125W
R125 681K +-1% .125W 681K +-1% .125W
Q1,4 MOSFET N-CHAN E-MODE TO 204AE MOSFET N-CHAN E-MODE TO 204AE MOSFET N-CHAN E-MODE TO 3 SI MOSFET N-CHAN E-MODE TO 3 SI
Q5,8 NPN 2N2222A SI TO-18 PD=500MW2 NPN 2N2222A SI TO-18 PD=500MW
Q6,7 NPN 2N2222A SI TO-18 PD=500MW2 NPN 2N2222A SI TO-18 PD=500MW2 PNP 2N2907A SI TO-18 PD=400MW PNP 2N2907A SI TO-18 PD=400MW
U2 IC OP AMP GP DUAL 8 PIN DIP-P IC OP AMP GP DUAL 8 PIN DIP-P
U21,22,23,24 OPTO-ISOLATOR LED-TRIAC OPTO-ISOLATOR LED-TRIAC
CR3,4,5,6,7 DIODE-GEN PRP 180V 200MA D0-35 DIODE-GEN PRP 180V 200MA D0-35
CR11,14 DIODE-PWR RECT 400V 1A 50NS DO-41 DIODE-PWR RECT 400V 1A 50NS DO-41
T1 TRANSFORMER-POWER FOR E3614A TRANSFORMER-POWER FOR E3615A TRANSFORMER-POWER FOR E3616A TRANSFORMER-POWER FOR E3617A
T2,3 TRANSFORMER-PULSE; PRI IND:5MH TRANSFORMER-PULSE; PRI IND:5MH
A-19
