Chapter 3 Front-Panel Operation
Remote Interface Configuration
58
To Set the GPIB Address
To configure the power supply for the GPIB interface, proceed as follows:
1
Turn on the remote configuration mode.
You will see the above message on the front-panel display if the power supply
has not been changed from the factory setting. If “RS-232” appears, choose
“GPIB / 488” by turning the knob to the right.
2
Move to the GPIB address setting mode.
The address is set to “05” when the power supply is shipped from the factory.
Notice that a different GPIB address may appear if the power supply has been
changed from the factory setting.
3
Turn the knob to change the GPIB address.
The displayed address is changed when turning the knob to the right or left.
4
Save the change and turn off the I/O configuration mode.
The address is stored in non-volatile memory, and does not change when
power has been off or after a remote interface reset. The power supply displays
a message to show that the change is now in effect. If the GPIB address is not
changed, “NO CHANGE” will be displayed for one second.
Note
To exit the I/O configuration mode without any further changes, press the
“I/O Config” key until the “NO CHANGE” message is displayed.
GPIB / 488
ADDR 05
CHANGE SAVED
