Chapter 10 263
Replaceable Parts Lists and Locations
Hardware
This table corresponds to Figure 10-9 and Figure 10-10.
Reference
Designator
Description Agilent Part
Number
1 J1 Input Connector, 3.5 mm (m) (Option BAB) 08673-60040
2 1st LO OUT connector SMA (Option AYZ) 1250-1666
3 IF INPUT connector SMA (Option AYZ) 1250-1666
A22 A22 Preamp Assembly (Option 1DS) E4440-60444
A27 A27 Electronic Attenuator (Option B7J) E4440-60456
FL2 FL2 Band Pass Filter, 3.900 GHz (Option 122 or 140) 0955-1391
FL3 FL3 Low Pass Filter, 4.4 GHz (Option 122 or 140) 0955-0519
W7 W7 Cable, semi-rigid, For Option BAB 3.5 APC RF Input to
A14 Attenuator
E4440-20099
W45 W45 Cable, semi-rigid, LO OUT from front-panel to W46
(Option AYZ)
E4440-20095
W46 W46 Cable, semi-rigid, LO OUT extension cable from A21
SLODA 1st LO OUT to W45. (Option AYZ, for PSA ≤ 26.5 GHz)
E4440-20087
W48 W48 Cable, semi-rigid, FL1 Low Pass Filter to A22 Preamp
Assy. (Option 1DS)
E4440-20072
W50 W50 Cable, semi-rigid, Preamp Out from A22 Preamp to
Lowband (Option 1DS)
E4440-20079
W51 W51 Cable, semi-rigid, A19 SBTX/RYTHM out to A27
Electronic Attenuator (Option B7J)
E4440-20110
W52 W52 Cable, semi-rigid, A27 electronic attenuator to FL1, 3 GHz
Low Pass Filter (Option B7J)
E4440-20109
W78 W78 Cable, semi-rigid, FL2 to FL3 (Option 122 or 140) E4446-20047
W79 W79 Cable, semi-rigid, FL3 to A20 Lowband (Option 122 or
140)
E4446-20048
W88 W88 Cable, semi-rigid, SLODA LO Out to cable W83 Mixer LO
In (Option 123)
E4440-20087
