Agilent Technologies E444xAU Option H37 Service Guide

Chapter 10 275
Replaceable Parts Lists and Locations
Hardware
Reference
Designator
Description Agilent Part
Number
1 Bracket, 2.4 mm RF Input E4446-20004
J1 J1 Input Connector, 2.4 mm 5064-3970
W7 W7 Cable, semi-rigid, For standard 2.4mm RF Input to A14
Attenuator
E4446-20020
W8 W8 Cable, semi-rigid (with ferrites), A14 attenuator to A15
attenuator
E4446-20021
W20 W20 Cable (50), coax, 50 MHz Cal signal from A10 3rd
Converter J7 to A14 Attenuator
8121-0156
W33 W33 Cable, semi-rigid, A15 Attenuator to W34 E4446-20022
A14 A14 Input Attenuator (10 dB)/Switch) 33326-60009
A15 A15 Input Attenuator (60 dB) 33325-60009
