Agilent Technologies E444xAU Option H37 Service Guide

Chapter 10 277
Replaceable Parts Lists and Locations
Hardware
Reference
Designator
Description Agilent Part
Number
W7 W7 Cable, semi-rigid, For standard 2.4mm RF Input to A14
Attenuator
E4446-20020
W8 W8 Cable, semi-rigid (with ferrites), A14 attenuator to A15
attenuator
E4446-20021
W15 W15 Cable, semi-rigid, A9 2nd LO, J10 to Lowband, J5 E4440-20084
W18 W18 Cable (7), coax (with ferrites), 321.4 MHz A20 Lowband
assy to A10 3rd Converter J2
E4440-60372
W20 W20 Cable (50), coax, 50 MHz Cal signal from A10 3rd
Converter J7 to A14 Attenuator
8121-0156
W24 W24 Cable, semi-rigid, A21 FELOMA to A12 Synthesizer E4446-20036
W33 W33 Cable, semi-rigid, A15 Attenuator to W34 E4446-20022
W34 W34 Cable, semi-rigid, W33 to A19 SBTX/RYTHM E4446-20023
W35 W35 Cable, semi-rigid, YTO Output A18 YTO to A21 FELOMA E4446-20033
W36 W36 Cable, semi-rigid, A19 SBTX/RYTHM to FL1 Low Pass
Filter (except Option B7J)
E4446-20031
W37 W37 Cable, semi-rigid, FL1 Low Pass Filter to A20 Lowband
Assy. J1 (except Option 1DS)
E4446-20037
W38 W38 Cable, semi-rigid, LO signal A21 FELOMA to A19
SBTX/RYTHM
E4446-20030
W39 W39 Cable, semi-rigid, Bandpass Filter Output, 3.9 MHz
Bandpass Filter to A20 Lowband J4
E4446-20058
W41 W41 Cable, semi-rigid, A21 FELOMA to A20 Lowband Assy. E4446-20034
W43 W43 Cable, semi-rigid, AT1 to FELOMA J2 (SBTX) E4446-20049
W54 W54 Cable, semi-rigid, A20 Lowband J3 to FIFA middle
connector
E4446-20044
W55 W55 Cable, semi-rigid, A19 SBTX to FIFA rear connector E4446-20045
W56 W56 Cable, semi-rigid, FIFA to FL2 Band Pass filter E4446-20046
