Installation Note E8362-90004 5
Items Included in the Upgrade Kit
Check the contents of your kit against the following list. If any item is missing or damaged,
contact Agilent Technologies. Refer to “Getting Assistance from Agilent” on page 3.
Table 1 Option 040 Upgrade Kit (E8362-60109) to Extend the E8362B/C to 40 GHz
Ref.
Desig.
Description Qty Part Number
Parts for all analyzer options (except Option 014)
N/A Installation note (this document) 1 E8362-90004
N/A License key certificate 1 5964-5136
N/A Model number nameplate (for 40 GHz analyzer, E8363B) 1 E8363-80002
N/A Model number nameplate (for 40 GHz analyzer, E8363C) 1 E8363-80003
A21 SOMA 50 1 5087-7130
A23 Channel R1 detector
2 5087-7133
A24 Channel R2 detector
A25 Test port 1 coupler
2 5087-7518
A26 Test port 2 coupler
A27 Channel A first converter (mixer)
2 5087-7122
A30 Channel B first converter (mixer)
A38, A39 Bias tee (cable included) 2 5087-7233
N/A
Machine screw M3.0 x 18 (for attaching A23 and A24 detectors)
4 0515-0666
N/A
Machine screw M3.0 x 30 (for attaching SOMA 50)
4 0515-1349
N/A
Ribbon cable, A21 SOMA 50 to A16 test set motherboard
1 8121-0818
N/A
Cable, wrapped wire, detectors to A16 test set motherboard
2 E7340-60075
N/A
Test set deck front panel
1 E8364-00014
W1 A12 source 20 to A21 SOMA 50 1 E8364-20036
W2 A21 SOMA 50 to A22 switch/splitter 1 E8364-20034
W3 A22 switch/splitter to A23 channel R1 detector 1 E8364-20144
W4 A22 switch/splitter to A24 channel R2 detector 1 E8364-20024
W37 A23 channel R1 detector to A16 test set motherboard J204 1 E8364-60121
