Agilent InfinityLab LC Series Multicolumn Thermostats User Manual 80
3 Using the Module
Installing and Using Column ID Tags
The Column Tag Information Table
The Column Assignment dialog box, which you access using the Column
Assignment command of the dashboard context menu, shows the detailed
information about the columns attached to each position in the device. The
dialog box includes the Column Tag Information table, which contains all the
column-specific information stored on the column ID tags (see “Column Tag
Information” on page 81) plus the following possible additional columns:
By default, only the Column Tag Information table columns up to and including the
Injection column are displayed. Click the >> button at the top right of the table to
show the full table.
Tag Status Shows the status of the column ID tag:
• Empty: The position is empty or has a column without a column
ID tag.
• : A column with a column ID tag is installed at this position.
• : A column with a sealed column ID tag is installed at this
position.
• : A column with a prelabeled column ID tag supplied by
Agilent Technologies is installed at this position.
Location Shows the location in the device to which the plumbing of the valve
position leads.
For a valve thermostat cluster, the Column Host (the device where
the column is installed) is also shown.
Color Code Shows the color representing the column currently occupying the
valve position.
Import Present only when the CDS is an Agilent OpenLab CDS ChemSta-
tion Edition.
Click the icon to display a dialog box listing all the columns
entered in the ChemStation's Edit Columns table, from which you
can select appropriate information to import.
