Agilent N5161A/62A/81A/82A/83A MXG Signal Generators Service Guide
Troubleshooting
Getting Started with Troubleshooting
1-14
No GPIB Activity page 1-65
Unlocked Conditions page 1-65
Unleveled Conditions page 1-66
Troubleshooting the RF Path page 1-68
Troubleshooting the 6 GHz Electronic Attenuator page 1-68
Troubleshooting Harmonic Spurious page 1-69
Troubleshooting Non-Harmonic Spurious page 1-71
Troubleshooting Performance Test Problems page 1-72
Manual Performance Test Problems page 1-72
Automated Performance Test Problems page 1-73
Troubleshooting Adjustment Test Problems (N51
83A Only)
page 1-73
