Installation Note E4440-90318 5
Audio Input, Option 107
Contents
Tools Required
1. T-20 Torx driver
2. T-10 Torx driver
3. 9/16 inch nut driver
4. X-Acto knife
❏ PSA Series Spectrum Analyzer Service Guide. This manual is available as part of the
E444xAU Option OBW kits.
❏ Calibration software. Latest software information and downloads available at:
http://www.agilent.com/find/calibrationsoftware
❏ Test equipment supported by the calibration software.
❏ Microsoft Windows based personnel computer with LAN card and CD-ROM drive.
❏ Windows 2000 or Windows XP
❏ Crossover cable if PC or analyzer is not connected to network. Use a CAT, RJ45 cable
with cross pinning, Agilent p/n 8121-0545.
❏ Firmware A.0 9.00 or later. Download the latest revision from
http://www.agilent.com/find/psa_firmware, or order the Firmware Update kit.
Depending on your model number, the firmware update kit is ordered as:
Order E444xAU (Qty.1) Option UE2 (Qty. 1), where the “x” is the last digit of the
model number. For example: E4440AU option UE2.
Quantity
Description Agilent Part
Number
1 Installation Note This note
1 Option Upgrade Entitlement Certificate 5964-5141
1 PSA User's and Programmers Guide Vol. 1 --
1 PSA Specifications Guide --
1 Cable, Audio Input 8121-1432
1 Hex Nut 2950-0035
1 Audio board Assembly E4440-60264
1 Audio Input label for bezel E4440-80100
1 Digital IF Assembly E4440-60206
