LED Flashes 2x
Cause A connected photocell was interrupted
or actuated. A safety reversal may
have occurred.
Remedy Eliminate the obstruction cause and/or
check the photocell and replace if
necessary.
Acknowl-
edgement
Renewed impulse entry by means of
an external button, the radio receiver
or the T button.
If in the OPEN end-of-travel position, a
closing run will take place, otherwise it
will be an opening run.
LED Flashes 3x
Cause The CLOSE force limit has been
activated, a safety reversal has taken
place.
Remedy Remove the obstruction. If the safety
reversal took place for no apparent
reason, check the door mechanism or
the tension of the toothed belt.
If necessary, delete the door data
(see Chapter 11.1.1 ) and teach it in
again (see Chapter 4.1) or adjust the
tension of the toothed belt (see
Chapter 9.3 ).
Acknowl -
edgement
Renewed impulse entry by means of
an external button, the radio receiver
or the T button.
An opening run will take place.
LED Flashes 5x
Cause The OPEN force limit has been
activated. The door stopped while
opening.
Remedy Remove the obstruction. If the door
stopped before the OPEN end-of-
travel position for no apparent reason,
check the door mechanism or the
tension of the toothed belt.
If necessary, delete the door data (see
Chapter 11.1.1 ) and teach it in again
(see Chapter 4.1) or adjust the tension
of the toothed belt (see Chapter 9.3 ).
Acknowl-
edgement
Renewed impulse entry by means of
an external button, the radio receiver
or the T button.
A closing run will take place.
LED Flashes 6x
Cause Operator error/malfunction in operator
system
Remedy If necessary, delete the door data (see
Chapter 11.1.1 ) and teach it in again
(see Chapter 4.1). If the operator error
occurs again, replace the operator.
Acknowl-
edgement
Renewed impulse entry by means of
an external button, the radio receiver
or the T button.
An opening run will take place (OPEN
reference run).
LED Flashes 7x
Cause The operator has not been taught in
yet (this is only a message and not a
malfunction).
Remedy/acknowl-
edgement
Trigger the CLOSE learning cycle by an
external button, the radio receiver or
the T button.
LED Flashes 8x
Cause The operator requires an OPEN
reference run (this is only a notice and
not a malfunction).
Remedy/acknowl-
edgement
Trigger the OPEN reference run by an
external button, the radio receiver, or
the T button.
Note: This is the normal status after a power
failure if no door data is present or has
been deleted and/or the last door
position is not sufficiently known.
