TR10K001-A RE / 04.2009
9
Path of travel
The distance the door takes to traverse from the OPEN end-
of-travel position to the CLOSE end-of-travel position.
Symbols and abbreviations used1.3
Symbols:
Important note for avoiding damage to
property
Permissible arrangement or activity
Non-permissible arrangement or activity
Use protective gloves
Tighten the screws by hand
Tighten the screws firmly
Audible engagement
Remove and dispose of component or
packaging
Factory settings
If DIL switches are used to set the controls,
the following symbol indicates the factory
setting(s) of the DIL switches.
Abbreviation:
OKB = top edge of fascia frame
NOTE:
All dimensions in the illustrated section are in [mm].
2 Safety Instructions
Intended use2.1
This garage door is designed and intended for private use only
and may only be operated in connection with the garage door
operator supplied.
Note the manufacturer‘s specifications regarding the door and
operator combination. Potential hazards as outlined in
EN 12604 und EN 12453 are avoided by construction and
assembly according to our guidelines. Door systems which
are located in a public area and only have one protective
device, such as a force limit, may only be operated under
supervision.
Continuous operation is not permitted.
Non-intended use2.2
Use in the commercial sector is prohibited.
General safety instructions:2.3
Fitting, maintenance, repair and dismantling of the •
sectional doors and operators may only be carried out by
specialists (competent persons in accordance with
EN 12635).
In• the event of a door failure (sluggish operation or other
malfunctions), a specialist must be commissioned
immediately for the inspection/repair work.
The specialist must ensure that the applicable regulations •
on occupational safety, as well as the regulations on the
operation of electrical devices, are complied with. The
relevant national guidelines must be observed.
Before the door is put into service, it must be tested to •
make sure that it is mechanically sound, in perfect
working order as well as correctly balanced, making it
also easy to operate manually (EN 12604).
The application of the sectional doors is stipulated in •
EN 13241-1.
When the door is fitted, attention must be paid to •
potential hazards as defined in EN 12604 and EN 12453.
ENGLISH
