10
We recommend that you carry out
the following tasks with the helmet
resting on a level surface.
To remove the visor, raise it to the fully open
position
1
.
Start on one side of the helmet by pulling the visor
lock slider
2
downwards and detach the catches
from the visor. Repeat on the other side and remove
the visor.
To fit the visor, start on one side of the helmet with
the visor fully raised and insert the upper catch into
its seating on the mechanism base
3
.
Next, insert the visor lower catch into the visor lock
(pulling the slider downwards may help)
4
. Repeat
on the other side of the helmet. Lower the visor and
make sure it is working properly.
N.B. It the visor does not line up properly with
the rubber seal on the helmet, you may need to
adjust or replace the visor mechanism base. In
such case, contact AGV for assistance.
1
2
3
4
