3 VISOR
3.1 VISOR MECHANISM
› Upper catch seating
1
;
› Teeth on visor mechanism base
2
;
› Visor lock
3
;
› Visor lock slider
4
.
3.2 REMOVING/FITTING THE
VISOR
The non-scratch polycarbonate visor is fitted with
catches which click into the visor mechanism
base. The visor tooth interact with the teeth on the
mechanism base to provide stability when the visor
is open in different positions.
› Upper catch
1
;
› Visor tooth
2
;
› Lower catch
3
.
Only use AGV GT6 visors.
1
3
2
1
4
3
2
