9 THE RESCUE PULL SYSTEM
Only to use in case of emergency after an accident. The RPS allows a quick removal
of the cheek pads by the first aid staff.
The mechanism works thanks to two red laces that are placed below the cheek pads
and are connected to the quick release buttons which secure the cheek pads to the
inner polystyrene. Pulling the laces, the buttons get released, thus allowing to re-
move the cheek pads without previously taking off the helmet from the user’s head.
9.1 ACTIVATION
Condition: the helmet wearer is lying on
the ground in supine position.
• Cut or loosen the retention system.
• Pull the two red laces (1) – first one,
then the other – until you perceive
that the automatic buttons get
released.
→ The cheek pads are now unfastened
from the helmet and they can be
removed.
Warning! Gently remove the cheek pads moving the user’s hear as little as
possible.
Never pull the emergency red laces while riding.
Do not remove the cheek pads using the RPS to perform the maintenance.
Only use AGV original cheek pads.
Use the RPS only in case of emergency.
10 THE BREATH DEFLECTOR
10.1 REMOVAL
Condition: place yourself in a sitting posi-
tion laying the helmet on your knees.
• Grab the breath deflector and re-
move it from its housing, first de-
taching the lateral attachment
teeth (1), then the central one (2).
10.2 INSTALLATION
Condition: place yourself in a sitting posi-
tion laying the helmet on your knees.
• Clasp the breath deflector into its
housing, first inserting the central
hooking tooth (2), then the lateral
ones (1).
