36 Front panel Header for RACK (JRACK1)
RACK_EXTRST_N 1 2 BMC_I2C_08_SCL
GND 3 4 BMC_I2C_08_SDA
BMC_I2C_01_SCL 5 6 GND
BMC_I2C_01_SDA 7 8 RACK_PWM0
GND 9 10 RACK_TACH0
RACK_PMBUS _CLK 11 12 GND
RACK_PMBUS
_DATA
13 14 RACK_PWM1
PMBUS_ALERT_N 15 16 RACK_TACH1
RACK_CHASSIS_
OPEN
17 18 RACK_GPIO_EXIN
GND 19 20 CHASSIS_1U2N_N
37 SSI Front panel Header (JSSI1)
FP_HDR_PWR_LED 1 2 FP_PWR (+3V3_S5)
KEY (no pin) 3 4
HDR_CHASSIS_ID_
LED (+5V_S5)
FP_PWR_LED_L 5 6 ID_LED_OUT_N
HDD_LED_P
(+3V3_S5)
7 8 SYS_HEALTH2#
HDD_LED_N 9 10 SYS_HEALTH#
FP_PWR_BTN_N 11 12 LAN1_ACTLED_PWR
GND 13 14 PHY1_LED0_N
SW_COLD_RST_N 15 16 BMC_I2C_08_SDA
GND 17 18 BMC_I2C_08_SCL
BMC_ID_IN_N 19 20 CHASSIS_OPEN
TEMP_SENSOR (NC) 21 22 LAN2_ACTLED_PWR
FP_NMI_BTN_N 23 24 PHY1_LED1_R
38 Chassis Intrusion Header (JINTRUDER1)
1 CHASSIS_OPEN_N
2 GND
39 BMC BUZZER Header (JBUZZER1)
1 +5V_S0
2 BMC_BUZZER
41 IPMB_PMBus BOX Header (JBMC_I2C1)
1 BMC_I2C_01_SDA
2 GND
3 BMC_I2C_01_SCL
4 NC
42 BMC COM2 Header (JCOM1)
DCDB 2 1 DSRB
RXDB 4 3 RTSB
TXDB 6 5 CTSB
DTRB 8 7 RIB
GND 10 9 NC
