Chapter 4. BIOS Conguration SettingsAuriga User Manual
DDR4 Common
Options
DRAM Timing
Conguration
I Accept
TrrdL
Activate Delay
Time, same bank
group
Tfaw Ctrl
Auto
Manual
Tfaw
Min=0x6
Max=0x36
TwtrS
Minimum Write
to Read Time,
different bank
group
TwtrL
Minimum Write to
Read Time, same
bank group
Twr Ctrl
Auto
Manual
Twr
Min=0xa,
Max=0x51
Trcpage Ctrl
Auto
Manual
Trcpage
Min=0x0,
Max=0x3ff
TrdrdScL Ctrl
Auto
Manual
TrdrdScL
Min=0x1,
Max=0xf
TwrwrScL Ctrl
Auto
Manual
TwrwrScL
Min=0x1,
Max=0x3f
Trfc Ctrl
Auto
Manual
Trfc
Min=0x3c,
Max=0x3de
Trfc2 Ctrl
Auto
Manual
Trfc2
Min=0x3c,
Max=0x3d
Trfc4 Ctrl
Auto
Manual
Trfc4
Min=0x3c,
Max=0x3d
