Aikoh Engineering RZ-50 User Manual

－25－ －26－
H
①PEAKsetting
Pressthe keytoshowPintheupperleftcornerofthescreen.
※Thepeakmatingvalueisshowninthemaindisplayandthepeakunmatingvalue
inthesubdisplay.
※WhenPisflashing,onlythepeakmatingvalueisshown.
②Checkingtheunit
Selecttheunitwiththe keyaccordingtomeasurement.
③Connectormating/unmatingmeasurement
Conductconnectormating/unmatingmeasurement.（Toholdthegagebyhandfor
measurement,besurethatthegageisheldverticallyandwillnotshakeduringthe
measurement.）
④Checkingthemating/unmatingvalues
Amatingforceandunmatingforcecanbemeasuredbyonemeasurement
operation.Aforcevaluehavingtheminussignisthematingforceandaforcevalue
havingnosignistheunmatingforce.
Pressingthe keystoresdatainthememoryoftheRZgage.
Aftermeasurement,connectthegagetoaprinterandprintdatacollectively.
（Bypressingthe keywiththeprinterconnected,datacanbeprinted
individually.）
※Fortheprocedurethatfollows,seeMeasurement①<Measurementbyuseof
thememoryfunction>.
■Formeasurementofmating/
unmatingforcesofconnectors,etc.
Memoryfunctionofthegage
Amatingvalueandunmatingvalueare
storedinthememoryandindicatedby
oneoperation.
PEAK
TRACK
MEMO
PRT
Measurement③
＜Connectormating/unmatingmeasurement＞
ForceCalibrationProcedure
Donotusea
damagedhookor
deformedhook.
・Thehookmaybebrokenorslipoutofyourhandto
causeinjury.Ortheobjectbeingmeasuredmay
falltocauseseriousinjury.
・Applyaforcetoapointwheretheextensionline
ofthemeasuringshaftandthehookcross.Ifa
forceisappliedtothetipofthehook,thehook
maybedeformedorbrokentocauseserious
injury.
・Theforcesensormaybebroken.Applicationofa
largerforcemaybreakthebodycaseorinternal
componentstocauseaccidents.
・Theweightofthefixturewillbeloadedasaforce.
Useafixturetheweightofwhichislessthan
10%oftheratedcapacityofthegage.
・Whensecuringanattachment,donottightenit
withatooltoostrongly.Alargeloadwillbe
appliedtothesensortobreakit.Afterturningon
thepower,secureitwhilecheckingtheindicated
value.
Donotapplyaforce
exceedingtherated
capacity.
Neveroperatethegagewithoutthestandardweight.
Iftheforcefluctuatesduringoperation,accurateforce
calibrationcannotbeperformed.
Inthisoperation,thenumericvaluemaybechangedonly
within±10%ofthesuspendedweightinordertoprevent
abnormalcalibration.
SecuretheRZgageonateststand.
※RZ-2(20Ntype)isusedasanexamplefor
explanation.
※Theforcecalibrationcannotbeperformed
whileholdingthegagebyhand.
①
