－7－ －8－
N
N
（Forstoringdatainmemory,seepage20.）
Maximum500piecesofdataor500setsofdatacanbestoredinthememory.
Whendataisbeingstored,thismarklightsup.
Pressingthe keyrecordsthemeasuredvalueandthenumberofpieces
ofrecordeddataisshownatthebottom.
BothPEAKandTRACKvaluesarerecorded.However,sincethefirstmemory
conditionsarefixed,changingPEAK/TRACKandunitsofmeasurementare
notallowedinthesecondandfollowingoperations.
Tostoredataafterchangingtheconditions,pressthe keywiththe
keyheldpressedtoclearallstoreddataonce.Assoonasdatahasbeen
cleared,themarkMwillgooutandthenumberofpiecesofdatawill
becomezeromomentarilyandthengoout.
OnlywhenthemarkPisshownlitinthepeakmode,thecompressivepeak
valueandtensilepeakvaluearestoredasasetinthememory.
M(Memorymode)
MEMO
MEMO
FUNC
N
Eachtimethe keyispressed,Pchangesitsstatusas
flashing→on→off.
Pflashing･････Thehighestmeasuredvalueofeithertensileor
compressivevalueisacquiredasthepeakvalue.
Pon･････････Thecompressivepeakvalueisindicatedina
largesizeandthetensilepeakvalueisindicated
inasmallsizeinthesubdisplay.
Poff･･･････････TRACK(trackvalue)isindicated.
Thevalueisresettozerowiththe keyorbyshortcircuiting
theI/Oconnector(pin15‒pin17).
P(Peakmode)
PEAK
TRACK
ZERO
N
HlightsupwhentheI/Oconnectorpin14andpin17are
shorted.Anumericvalueatthetimethecontactisonremains
showninthemaindisplay.
Hflasheswhenthecontactisturnedoff(pin14andpin17
opened)thattakesplaceaftercontactonandanumericvalueat
thetimethecontactisoffremainsshowninthesubdisplay.
Hgoesoutafterthevalueisresettozerowiththe keyor
shortcircuitingtheI/Oconnectorpin15andpin17.
Contacton/offmeasurementofswitches,etc.canbeperformed.
※Fordetails,seepage23.
H(Externalcontactholdmode）
ZERO
Clightsupwhenupper/lowerlimitvaluesaresetafterselecting
thecomparatorfunctionenableintheusersettingmode.
（Forsetting,seepage12.）
Whentheforcevalueiswithintherangeofthesetvalue,OK,
whenoutsideoftheplusrange,Hiandwhenoutsideofthe
minusrange,LowareindicatedbytheLEDandcorresponding
signalsareoutputfromtheI/Oconnector.
C(Comparatormode)
PriortoUse
＜Charging＞
Besuretousethe
includedACadapter.
Theuseofanadapterotherthantheincluded
ACadapterwilldestroytheaccuracyandina
worsecase,maycausemalfunctionorfire.
Thegagehasbeenchargedinthefactory,butsinceaminutecurrentisconsumed
evenwhenthepowerisoff,thecharginglevelmighthavedropped.Priortouse,
chargethegagewiththeincludedACadapter.
USBconnector
DedicatedcableModelRZ-USB
ACadapterMODEL-780
①ConnectthededicatedUSBcabletotheincludedACadapterandconnectittothe
USBconnectorofthegage.
ConnecttheACadapteritselftoanACoutlet.
●Afterthepoweristurnedon,ittakesabout5secondsforthebatteryremaining
chargemarktoindicatetheaccuratepresentremainingcharge.
※Whenthegagehasbeenchargedfully,chargingwillbestoppedautomatically.
However,forsafety,donotchargethegagelongerthan24hours.Normallythegage
willbechargedfullyinabout4.5hoursfromthestateofL.b(lowbattery)andcan
beusedcontinuouslyforabout30hours.
●Ifthebatterywarning[L.b.]flashesorthewarningbuzzersoundsimmediatelyafter
charging,apossiblecauseisthattheincorporatedbatterieshavereachedtheend
oflifeandthebatteriesneedtobereplacedwithnewones.However,thegageis
designedtodisablereplacementofthebatteriesbytheusertoensurethatthe
qualityoftheincorporatedbatterieswillnotaffecttheaccuracyofthegage.
Whenthebatteriesneedtobereplaced,pleasecontactthedealerorAikoh
Engineering.
