Aikoh Engineering RZ-50 - Usage Cautions and Precautions; Force, Environment, and Temperature Limits; Mounting and Shaft Handling Precautions

－3－ －4－
Donotapplyaforce
exceedingtherated
capacity.
Theforcesensormaybebroken.
Applicationofalargerforcemaybreak
thebodycaseorinternalcomponents
tocauseaccidents.
Donotuseorstorethe
gageinthe
environmentdescribed
ontherightside:
・Anenvironmentwherethegagemay
beexposedtowater.
・Anenvironmentwherecondensation
mayoccur.
・Adustyenvironment.
・Anenvironmentwherethegagemay
beexposedtooilorchemicals.
Usethegagewithinits
workingtemperature
range(0to+40℃).
Theuseofthegageoutsidethe
workingtemperaturerangemaycause
malfunction.Theworkinghumidity
rangeis20%to60%RH.
Makesurethat
mountingscrewsareof
correctlength.
Donotapplyaforcetothemeasuringshaftinabendingortorsionaldirection.
Whenmountingthegage,selectsuch
mountingscrewsthatwillnotenter
thebodymorethan6mm.Theuseof
ascrewlongerthanthismaydamage
thebodycase.
CAUTION
Aforceinbendingdirection
Aforceintorsionaldirection
CheckingtheContentsofthePackage
Priortouse,makesurethatthefollowingitemsarecontained:
Displayreversingfunction
Whenthemeasuringshaftisdirected
downward,thedisplaymaybereversed
upsidedowntomakethedisplayeasyto
read.
Forthereversingprocedure,seepage16.
