5.1 Parameter
1. Voltage: AC 80V--260V ; 50-60HZ
2. Power: 15W
3. Working Temperature: -10℃--60℃
4. Storage Temperature：-30℃--70℃
5. Relative Humidity：<90%（25）>
6. Axis Number: 1 axis,2 axis,3 axis
7. Input Signal: 5V TTL/5V RS422
8. Input signal Frequency: <50MHZ
9. Resolution (Linear Encoder): 0.1 um, 0.2 um, 0.5 um, 1 um, 2 um,
2.5 um，5 um，10 um
10. Highest Resolution(Rotary Encoder): <1000000ppr
11. Weight: 1.5KGS
12. Dimension:295*175*65mm
13. DB9 Pin diagram
5 4
3 2
1
9
8
7 6
44
Appendix
DB9-5V TTL
DB9-5V RS422
Pin
1 2 3 4 5 6 7 8 9
Signal
Empty
0 V
Empty
Shield
Empty
A
+5 V
B R
Color Black
Shielding
Yellow Red
Green
Brown
Pin
1 2 3 4
5
6 7 8 9
Signal
A-
0 V
B- Shield Z- A
+5 V
B R
Color
Orange
Black Blue
Shielding
White Yellow Red
Green Brown
