Direct to Device (Network) Coupling
Direct to Device (Network) Coupling is an option with AIM modules. The AIM design
includes on-board Bus Network circuitry that is software selectable. This allows the user to
connect directly to a single terminal device without the need for any bus coupling. The
Network Coupling mode, selected by the user via software controls, provides a terminated
MILbus network simulation on the AIM module for direct connection between the AIM
module/PBA.pro Analyzer and the terminal under test.
The PBA.pro Bus Analyzer Software allows the user to select
Isolated, Transformer, Direct or Network Emulation, through
the System overview controls. Use of an AIM Module without
the PBA.pro software is accomplished with library setup calls.
