CHAPTER 13
64 65
SOLO 2 DL
In case the vehicle ignition system has no output you need to connect Solo 2 DL to
the low voltage of the coil as shown in the following images.
Point 1: low voltage of the coil
Point 2: connected to the spark plug
Point 3: connected to the +12V of the battery
Once Solo 2 DL connected to RPM signal you can set its parameters in channels layer
of Race Studio 3.
