AIMS Power www.aimscorp.net
AIMS Power entire line of Global LF inverters have been processed with a conformal coating on the PCB,
making it water, rust, and dust resistant as well as corrosion resistant.
While these units are designed to withstand corrosion from the salty air, they are not splash proof.
3 Installation
3.1 Location
Follow all the local regulations to install the inverter.
Please install the equipment in a location of Dry, Clean, Cool with good ventilation.
Working temperature: 10 40‐ ℃‐ ℃(-14 to 104 )℉ ℉
Storage temperature: 40 70 (‐ ‐ ℃ -40 to 158℉ ℉)
Relative Humidity: 0% to 95%
，
non-condensing
Cooling: Forced air
3.2 DC Wiring
It is suggested the battery bank be kept as close as possible to the inverter. The following is a suggested
wiring option for 3 meter DC cable.
Please find the following minimum wire size. In case of DC cable longer than 3m, please increase the cross section of
cable to reduce the loss.
Power DC Input voltage Wire Gage
1KW 12V AWG 1/0
1KW 24V AWG 4
1.5KW 12V AWG 1/0
1.5KW 24V AWG 4
2KW 12V AWG 1/0
2KW 24V AWG 1/0
2KW 48V AWG 4
3KW 12V AWG 4/0
3KW 24V AWG 1/0
3KW 48V AWG 4
4KW 24V AWG 1/0
4KW 48V AWG 1/0
5KW 24V AWG 4/0
5KW 48V AWG 1/0
6KW 24V AWG 4/0
6KW 48V AWG 1/0
CAUTION
The torque rating range for DC terminal is 12.5NM-20.5NM, and the suggested torque rating is 17NM.
Over torqueing may cause the bolt to break.
17
