Aiphone GT-1C User Manual

- 10 -
%HHS
%HHS
%HHS
ALARM ACTIVATED.
ALARM ACTIVATED.
Pressing the [ OPTION] button allows for operation of connected units
to be performed such as turning lights on and off.
1 Press and lock the emergency alarm switch (or when there is a line -
off trouble).
2 An alarm will sound from the residential station, and a warning signal
will be sent to the security guard station.
3 When there is a call from the security guard station, the warning sound
will change to a call tone that will sound for the set amount of time.
The STATUS LED blinks.
4 Press the [ TALK] button to communicate with the security guard
station. The STATUS LED will light up. After communication, the
emergency alarm will begin to sound again.
5 Release the lock position of the emergency alarm switch to return to
the standby position (restore the system to normal status).
OPTION button
Emergency alarm
6-1
6-2
6
ALARMS AND RELATED INFO.
NOTES: 1. On the residential station, the emergency alarm and call tone will
be emitted at level 10 (HIGH) volume, regardless of the volume
setting.
2. The emergency alarm function can be activated even when the sys-
tem is in use. (Alarms can be activated at the same time by up to 5
units.)
3. Residential stations within the same residence will be unable to
receive normal calls while the emergency alarm is sounding. It is
only possible to respond to calls from the security guard station.
4. During the emergency alarm, the entrance station cannot make
calls to the residential station or to the security guard station that
are producing emergency alarms.

Aiphone GT-1C Specifications

General

Mounting	Wall mount
Display	3.5 inch LCD
Power Source	Supplied by GT-BC, GT-BCX, GT-VBC
Wiring	2-wire
Communication	Hands-free (VOX) or push-to-talk
Operating Voltage	24V DC
Operating Temperature	0°C to +40°C (+32°F to +104°F)
Housing Material	ABS plastic
Call Tone	Electronic
