Aiphone IX-DVF User Manual

76
Settings and Adjustments
Configuring the device on a PC
4
Chime
Configure the chime tone that plays from this device linked with the set schedule.
Click [Chime].
Or, click "Chime" in the Setting menu to display the Chime screen.
■ Weekly Schedule
Configure the chime tone start time and the chime tone for every day from Sunday through Saturday.
50 schedules can be set for each day.
How to configure the Weekly Schedule
1. Configure "Start Time" and "Chime" for each day of the week.
2. When done, click [Update].
Entry Description Settings Default values
Start Time Configure the time to begin playing the
chime tone.
00:00 - 23:59 -

Aiphone IX-DVF Specifications

General

Resolution	720p
Video Compression	H.264
Ingress Protection	IP65
Vandal Resistance	IK08
Operating Voltage	48 VDC (PoE)
Power Source	PoE (IEEE 802.3af)
Operating Temperature	-40° to 140°F (-40° to 60°C)
Communication	IP
Call Tone	Chime
