Air Techniques, Inc. Page 8
AS10, AS12, AS21, AS22, AS30,
AS40, AS50, AS70, & AS100
SITE REQUIREMENTS
Service Clearance:

Allow 12" on all sides for all models.
Ambient Temperature:

Must not exceed 105°F
Air System Plumbing Connection:

3/8" F.N.P.T. Shut-off valve and a 6 ft. pressure hose (supplied)

Air distribution piping for all models - 1/2", type "L" or type "K" copper

If pipe volume is too great, more than 235 in
3
or more than 100 ft. of 1/2" diameter
pipe, a pressure regulator should be installed between the main tank and the distribution
piping. Set pressure to pressure switch cut in value (factory set at 85 PSI).
Environmental:
Operating

Indoor use at altitudes up to 2000m. Temperature 5 to 40°C (41 to 105°F).

Maximum relative humidity 80% for temperatures up to 31°C, decreasing linearly to 50%
relative humidity at 40°C.

Supply voltage fluctuation of +/- 10% of nominal voltage.
Storage and Transport:

Temperature, -18 to 65°C (0 to 150°F).

Relative Humidity, 0 to 90%.
IEC 60601-1 Classification:

Protection against electric shock (5.1, 5.2): Class I

Applied Parts: There are no Applied Parts.

Protection against harmful ingress of water (5.3): Ordinary, IPXO

Degree of safety in the presence of flammable
anesthetics mixture with air or with oxygen or with
nitrous oxide (5.5):
Not suitable.

Mode of operation (5.6):
- All Modes Except AS100: Continuous
- AS100 Only: 50% Duty Cycle; Maximum
Continuous ON Time of 20 Min
