Adjusting the A/D Reading
The sensor values should range from 750-1250 during install and after
the break-in period, a reading of 500-1500 is acceptable when empty.
Note: When tightening the bolts, ALWAYS torque the nut, NOT the bolt
head. The bolt head should be in the bolt head holder, which is built
into the bracket.
1. Loosen the nut on the plastic nut end of the sensor.
2. At the plastic nut where the cable enters the deection sensor,
exert DOWNWARD pressure if the reading is above 1250
or UPWARD pressure if the reading is below 750 with your
ngers until the A/D reading is between 750 and 1250. Continue
to apply pressure to maintain the desired A/D reading during the
torque procedures in step 3.
3. Tighten the nut on the side of the sensor bracket where the cable
end exits and torque to 60 ft/lbs. Continue to apply pressure
with your nger to the plastic nut during torquing in order
to maintain the desired A/D reading. If the A/D readings are
still within the 750 to 1250 range after the nuts on both sides of
the sensor bracket have been torqued to 60 ft/lbs, continue to
instructions for the Final Sensor Torque.
DOWNWARD pressure
UPWARD pressure
