NOTE: THIS FAN MUST BE INSTALLED BY A LICENSED AND QUALIFIED
ELECTRICIAN IN ACCORDANCE WITH LOCAL AUTHORITY REGULATIONS
3
FAN ASSEMBLY & PARTS LIST - WITHOUT LIGHT KIT
Unpacking your Fan
Unpack your fan and check the contents. Please check each item prior to installation, should you nd any issues please
contact the Warranty Helpline on 1300 116 305 for assistance. To reduce the chance of marks or possible damage
please only remove the parts when required for installation.
To avoid possible electrical shock, be sure
electricity is turned off at the main fuse box
before assembling and wiring the fan.
WARNING
Part Quantity Part Quantity
Hanger Bracket 1 Fan Motor 1
Hanger Bracket Screws 2 ABS Blades 4
Ceiling Bracket Covers 1 Blade Screws 4
DC Receiver 1 Bottom Cover 1
MCU Wall Controller 1
Hanger Bracket
Hanger Bracket Screws
DC Receiver
Blades
Blade Screws
Fan Motor
Ceiling Bracket Cover
Downrod
Downrod Cover
Hanger Ball
Ceiling Bracket Screws
Top Motor Cover
MCU Wall Controller
