AIREDALE DR Series - Horizontal case size 3 (2 Fans); Vertical case size 3 (2 Fans)

Dry Cooler
Condensers
14 Dry Coolers Technical Manual 9308503 V2_06_2020
Installation
Horizontal case size 3 (2 Fans)
DIMENSIONS (mm)
Standard Fan
A B C D
E F G
DR25
1167 2177 1917 232 32 1000 234
DR30
1167 2177 1917 232 32 1000 234
DR35
1167 2177 1917 232 32 1000 234
DR45
1167 2177 1917 232 32 1000 234
Vertical case size 3 (2 Fans)
DIMENSIONS (mm)
Standard Fan
A B C D E F G H
DR25
1918 232 32 920 1126 500 1167 700
DR30
1918 232 32 920 1205 500 1167 700
DR35
1918 232 32 920 1126 500 1167 700
DR45
1918 232 32 920 1205 500 1167 700
F
H
58mm
7/8" INLET CONNECTION
(DISCHARGE)
7/8" OUTLET
CONNECTION (LIQUID)
(FIXING CENTRES)
G G
D C E
B
A
F
G
B
D C E
A
O
12.7
F
G
B
A
D C C E
O
12.7
F
D
E
G
B C
A
(FIXING CENTRES)
E
F
A
O
12.7
150mm
D
FIXING CENTRES
H
O 12.7
A
A
D
F
E
B
C
G
H
150mm
B
G
C
