AIREDALE DR Series - Mechanical Data; Dimensions - Horizontal; Dimensions - Vertical; Construction & Materials

Dry Cooler
Condensers
24 Dry Coolers Technical Manual 9308503 V2_06_2020
Technical
Mechanical Data
(1)Nominal data based on 35°C ambient and 45/40°C Water entering / leaving. All performance data is supplied in accordance with BS EN 14511-1:2013
(2) Overall dimensions for clearance
DR10 DR12 DR15
Total Heat of Rejection DR (1) kW 11.1 13.7 15.3
Dimensions - Horizontal (2)
H x W x L mm 1167 x 1000 x 1095 1167 x 1000 x 1095 1167 x 1000 x 1095
Dimensions – Vertical (2)
H x W x L mm 1126 x 1167 x 1100 1205 x 1167 x 1100 1126 x 1167 x 1100
Weight
Machine kg 96 106 110
Construction
Material/Colour
Galvanised Sheet Steel, Epoxy Baked Powder Paint - Light Grey (RAL
7035)
Dry Cooler Air Cooled - Copper Tube/Turbulated Aluminium Fins
Total Face Area m² 0.91 0.91 0.91
Nominal Airow m³/s 2.3 3.3 1.9
Discharge H Horizontal or -V Vertical (Please Specify at Order)
Std Fan & Motor AC EC AC
Quantity 1 1 1
Diameter mm 630 710 630
Maximum Speed rpm 895 930 895
Dry Cooler
Internal Water Volume L 6.6 6.6 11.9
Nominal Flowrate l/s 0.53 0.65 0.7
Pressure Drop kPa 11.9 17.8 20.7
OPTIONAL EXTRAS
EC Fan
Dimensions - Horizontal
H x W x L mm 1167 x 1000 x 1095 - 1167 x 1000 x 1095
Dimensions - Vertical
H x W x L mm 1205 x 1167 x 1100 - 1205 x 1167 x 1100
Weight
Machine kg 88 - 101
