AIREDALE DR Series - Operating Limits; Standard Variable Speed Head Pressure Control; Optional On;Off Head Pressure Control

Condensers
Dry Coolers
19
Dry Coolers Technical Manual 9308503 V2_06_2020
Technical
Performance Data – Dry Coolers
Standard Dry Cooler Fan
Water Entering /
Leaving
Ambient
Temperature °C 25°C 30°C 35°C 40°C 45°C
Output Output Output Output Output
(kW) (kW) (kW) (kW) (kW)
DR10
35°C/30°C 11 - - - -
40°C/35°C 19.6 11 - - -
45°C/40°C 28.1 19.6 11.1 - -
50°C/45°C 36.6 28 19.6 11.1 -
55°C/50°C 45 36.4 27.9 19.5 11.1
DR12
35°C/30°C 13.6 - - - -
40°C/35°C 24.5 13.7 - - -
45°C/40°C 35.2 24.5 13.7 - -
50°C/45°C 45.9 35.1 24.5 13.8 -
55°C/50°C 56.6 45.7 35.05 4.4 13.8
DR15
35°C/30°C 15..4 - - - -
40°C/35°C 25.6 15.3 - - -
45°C/40°C 35.6 25.4 15.3 - -
50°C/45°C 45.4 35.2 25.2 15.2 -
55°C/50°C 55.2 44.9 34.9 25 15.1
DR20
35°C/30°C 18.3 - - - -
40°C/35°C 31.9 18.3 - - -
45°C/40°C 45.1 31.7 18.3 - -
50°C/45°C 58.1 44.8 31.6 18.3 -
55°C/50°C 71.5 57.7 44.4 31.4 18.3
DR25
35°C/30°C 24.4 - - - -
40°C/35°C 43.1 24.5 - - -
45°C/40°C 61.5 43 24.5 - -
50°C/45°C 79.7 61.2 42.9 24.5 -
55°C/50°C 98 79.3 60.9 42.8 24.6
DR30
35°C/30°C 30.6 - - - -
40°C/35°C 54.5 30.7 - - -
45°C/40°C 78 54.5 30.8 - -
50°C/45°C 101.4 77.8 54.4 30.9 -
55°C/50°C 124.9 101 77.5 54.3 30.9
DR35
35°C/30°C 34.8 - - - -
40°C/35°C 57.4 34.6 - - -
45°C/40°C 79.5 56.9 34.3 - -
50°C/45°C 101.4 78.7 56.4 34.1 -
55°C/50°C 123.3 100.4 77.9 55.9 33.9
Standard Variable Speed Head Pressure Control
Minimum Ambient Air DB °C -20°C
Maximum Ambient Air DB °C +48
Optional On/Off Head Pressure Control
Minimum Ambient Air DB °C -0°C
Maximum Ambient Air DB °C +48
(1) For conditions outside those quoted, please contact Airedale.
Operating Limits
