AIREDALE DR Series - Horizontal case size 1 and 2 (1 fan); Vertical case size 1 and 2 (1 fan)

Condensers
Dry Coolers
13
Dry Coolers Technical Manual 9308503 V2_06_2020
Installation
Horizontal case size 1 and 2 (1 fan)
Vertical case size 1 and 2 (1 fan)
B
F
G
D C E
D
A
H
150mm
O 12.7
A
O
12.7
F
E
B
C
G
B
F
G
D C E
D
A
H
150mm
O 12.7
A
O
12.7
F
E
B
C
G
DIMENSIONS (mm)
Standard Fan
A B C D
E F G
DR10
1167 1095 820 246 32 1000 234
DR12
1167 1095 820 246 32 1000 234
DR15
1167 1095 820 246 32 1000 234
DR20
1167 1095 820 246 32 1000 234
DIMENSIONS (mm)
Standard Fan
A B C D E F G H
DR10
822 246 32 920 1126 500 1167 700
DR12
822 246 32 920 1205 500 1167 700
DR15
822 246 32 920 1126 500 1167 700
DR20
822 246 32 920 1205 500 1167 700
