Dry Coolers
9
Dry Coolers Technical Manual 9308503 V2_06_2020
Installation
Vertical Airow
For units selected with a vertical airow, the ambient temperature sensor should be mounted where shown in gure 1.
This will be for transport purposes only. Once the unit has been installed the bracket is to be removed from this location
and fastened to the bracket attached to the coil, shown in gures 3-5.
Figure 2: Sensor Mounting Location
Figure 3: New Sensor Bracket
2 OFF M5 NUTSERTS
