AIRMAC T20D - Yanmar Diesel Compressor Components

Instruction Manual
Airmac Air Compressors
2019-06-07
© Glenco Air & Power Pty Ltd
10
Item
Description
Item
Description
1
Compressor Pump
13
Wheel
2
Air Filter
14
Non-Return Valve
3
Crankcase Breather
15
Easy-Start Valve
4
Oil Fill Cap
16
Head Unloading Line
5
Oil Drain Plug
17
Safety Valve
6
Oil Level Sight Glass
18
Drain Valve
7
Diesel Engine
19
Air Receiver Pressure Gauge
8
Air Receiver Tank
20
Pilot Valve
9
Air Receiver Tank Nameplate
21
Key Start Panel
10
V-Belt Drive Guard
22
Emergency Stop Button
11
Wheel Mounting Bracket
Filter-Regulator (Behind Item 7)
12
Handle
Discharge Outlet (Behind Item 7)
Figure 2-7 Yanmar Diesel Air Compressor
