Figure 5-3 Preferred Bolted-Down, Foot-Mounting Arrangement – Option 1
(c) Another preferred method as shown in Figure 5-4 is for the compressor set to be mounted
on correctly selected and installed industrial vibration isolators. Specialist providers include
Mackay (www.mackayrubber.com.au) and Embelton (www.embelton.com). Caution: It is
critically important to specify whether the compressor set will be used in a fixed stationary or
mobile application when selecting such industrial vibration isolators.
Figure 5-4 Preferred Bolted-Down, Foot-Mounting Arrangement – Option 2
Certain mounting arrangements should never be used because they will likely result in misuse
damage to the unit, which is not covered by warranty. These are shown in Figure 5-5.
A vehicle or trailer-mounted compressor must only be operated when in a stationary, horizontal
position.
Fill the fuel tank with petrol or diesel as appropriate and check the engine oil level and refill if
necessary in accordance with the engine manufacturer’s instructions.
