4. Operation
4-13
H000040
4.6.3 Check fuel
Before starting operation, make sure to check the level of residual fuel so that fuel shortage during
operation can be avoided.
If necessary, drain condensate accumulated at the bottom of the fuel tank.
Do not, under any circumstance, bring lit cigarettes and/or matches
to the fuel.
The fuel is extremely flammable and dangerous. Be careful of fire
because it is very likely to catch fire.
Refuel only after stopping the engine, and never leave open fuel can
near the machine. Do not spill. It could cause a fire. When it is spilt,
wipe it up completely.
Refilling fuel tank should be done in an outdoor well-ventilated place.
Do not fill fuel oil up to the cap lever. When fuel tank is filled
up to the cap level, fuel oil will be overfilled due to volume
expansion caused by rise of ambient temperature. Further,
fuel will be possibly spilled from fuel tank due to vibration
caused during movement and/or transportation of machine.
4.6.4 Drain water sedimenter
Check if the red float“1”in the water sedimenter rises up to the water drain level“2”, then drain
water if it is near the drain level.
<Draining procedure >
① Place the lever“2”(provided on the top of sedimenter) to
“Close” position.
② Loosen the ring nut“3”and remove the cup“4”. In this case,
carefully remove the cup because it is filled with diesel oil, so
that it may not be spilled to soil the interiors.
③ After draining the condensate (water) accumulated in the
cup“4”, wash the cup in diesel oil. Then install it.
④ After turning the lever“2”to“OPEN”position and filling
the cup“4”with diesel oil, carry out the air bleeding
operation. (See 4.7.6)
Drain the condensate in container, and then dispose of
condensate according to the designated regulations.
D004
Fire prevention
2
1
4
3
