AirMan SG - Technical Specifications; Generator and Engine Specifications

8. Specifications
8-1
8.1 Specifications
Model
SDG45S-3A8
Specifications
Dual voltage type
Exciting system Brushless
Phase number Three-phase, four-wire system
Power factor % 80
Frequency Hz 50 60
Rated output kVA 37 45
Rated output kW 29.6 36
Voltage V 200 380/400 220 440
Current A 107 56.2/53.4 118 59.0
Voltage V 100 110
Exclusive terminal kVA
6.0
×
2 6.6
×
2
Generator
Single
phase
output
Outlet kVA
1.5
×
2 1.65
×
2
Model KUBOTA V3800-DI-T-K2B
Type
4-cycle, water-cooled, direct injection type with turbo
charged
Number of cylinders 4
Total displacement L 3.769
Rated output kW 38.0 45.6
Revolution per minute min
-1
1,500 1,800
Lubricating oil capacity L 13.2
Coolant capacity
(including radiator)
L
11
Battery 80D26R (12V) equivalent
Engine
Fuel tank capacity L 100
Overall length mm 1,870
Overall width mm 860
Overall height mm 1,220
Net dry mass (weight) kg 900
Weight・Mass
Operating mass (weight) kg 1,010
