8
ASSEMBLY
ATTACH THE WHEELS
Use a suitable spanner and
screwdriver to attach the wheels to
the compressor.
• Use the washers and spring
washer in the positions shown.
ATTACH THE SUPPORT FEET
Insert the support feet into the
position shown.
Use a suitable spanner and
screwdriver to attach each foot to
the compressor.
• Use the spring washer in the
positions shown.
ATTACH THE AIR FILTER
1. Screw the air filters into position.
• The air filter must be hand tight
only.
• One filter fits on each side.
