OPERATION & MAINTENANCE
INSTRUCTIONS
LS0620 - ISS 6ORIGINAL INSTRUCTIONS
24L AIR COMPRESSOR
MODEL NO: TIGER 8/250
PART NO: 2244000

Table of Contents

Questions and Answers

  • T
    Terri SullivanAug 6, 2025
    What to do if airmaster TIGER 8/250 Air Compressor has stopped and does not start?
    • N
      Norman JacksonAug 7, 2025
      If your airmaster Air Compressor has stopped and won't start, there are a few potential reasons. First, check the electrical connections, cleaning and tightening them if necessary. Second, the overload cutout switch may have tripped; in this case, switch off the compressor, wait about 5 minutes, press the reset button, and switch it back on. Finally, if the motor windings are burnt out, contact your dealer for a replacement motor.
  • R
    Robin HoffmanAug 12, 2025
    Why air is leaking from the non-return valve when airmaster Air Compressor is not running?
    • J
      Joseph HaleAug 12, 2025
      If air is leaking from the non-return valve when your airmaster Air Compressor is not running, it's likely due to a faulty non-return valve. To resolve this, completely drain the receiver of air, remove the valve end plug, carefully clean the valve seat and the gasket, and then reassemble.
  • M
    Michelle MooreAug 19, 2025
    Why airmaster Air Compressor is very noisy and makes a metallic knocking sound?
    • C
      Carl EllisonAug 19, 2025
      If your airmaster Air Compressor is making metallic knocking sounds, it means the compressor is damaged and needs overhaul. Return the machine to your nearest service agent.
  • K
    Kyle RobinsonAug 25, 2025
    What to do if air pressure from the regulator will not adjust on airmaster Air Compressor?
    • T
      Terri AtkinsonAug 25, 2025
      If the air pressure from the regulator on your airmaster Air Compressor won't adjust, the diaphragm within the regulator body is likely broken. Replace the regulator.
  • L
    Linda SmithAug 30, 2025
    Why airmaster TIGER 8/250 Air Compressor does not reach the set pressure and overheats easily?
    • R
      Rachel BennettAug 30, 2025
      If your airmaster Air Compressor doesn't reach the set pressure and overheats easily, it could be due to a blown compressor head gasket or a broken valve. Return the machine to your nearest service agent.

Summary

Introduction and Policies

Introduction

Read this manual thoroughly and follow instructions for safety and satisfactory service.

Guarantee Information

Product is guaranteed against faulty manufacture for 12 months. Keep receipt as proof.

Environmental Recycling Policy

Obligation to deal with WEEE according to regulations for environmentally sound disposal.

Parts and Servicing Contact Numbers

Provides telephone numbers for parts, service, and customer care.

Safety Precautions

Safety Symbols Explained

Electrical Connections Guide

Assembly Instructions

Attach the Wheels

Attaching wheels to the compressor using a spanner and washers.

Attach the Support Feet

Inserting support feet into the designated positions on the compressor.

Fit the Air Filter

Removing travel plug and screwing in the air filter hand-tight.

Oil Filler Cap and Moving

Fit the Oil Filler Cap

Removing the travel plug and inserting the oil filler cap.

Moving the Air Compressor

Caution to get assistance when lifting to prevent injury.

Before Use Checks

General Pre-Use Checks

Check ON/OFF switch, level ground, and supply voltage before connecting.

Check the Oil Level

Ensure oil level is halfway up the sight glass; add SAE30 oil if needed.

Operation Guide

Attaching Air Tools

Connecting air hoses and tools to the compressor outlet valve.

Turning the Compressor On

Plugging in and lifting the ON/OFF button to start the compressor.

Pressure Settings and Tool Removal

Set the Output Pressure

Adjusting the left hand outlet valve pressure using the regulator.

Understanding the Gauges

Explains reservoir and outlet pressure gauges.

Removing Tools from Air Hose

Setting pressure regulator to zero before removing or replacing tools.

Turning Off and Draining

Turning the Compressor Off

Steps for safely turning off the compressor and depressurizing the reservoir.

Draining the Reservoir

Draining condensate from the reservoir after each day's use.

Reset Button Functionality

Maintenance Schedule

Drain the Reservoir (Daily)

Draining condensate from the reservoir after each use.

Clean the Air Filter (Monthly)

Removing, cleaning, and refitting the air filter monthly or more often.

Component Checks and Specifications

Check the Non-Return Valve

Checking the non-return valve for leaks every 6 months.

Product Specifications

Details maximum pressure, voltage, air displacement, capacity, etc.

Troubleshooting Common Issues

Exploded Diagram

Parts List

Declaration of Conformity

Other Quality Products

airmaster TIGER 8/250 Specifications
