User & Installation manual
VHF- Communication Transceiver
Doc.-Nr:
DE-3000-800100e
KRT2
Revision 12.2
Jan. 2016
37 / 61
5.5 Unpacking and Inspecting the Equipment
Carefully unpack the equipment. Damages due to transportation must
immediately be reported to the shipping company. Save the shipping
container and all packing material to substantiate your claim.
For storage or reshipment the original packing material
should be used.
5.6 Mounting
In cooperation with the maintenance shop, mounting details are
specified. The maintenance shop can manufacture and install all
cables that may be required.
Avoid installing the unit in the vicinity of heat sources. Sufficient air-
circulation is required.
There must be sufficient space for cables and connectors.
Avoid sharp bends and wiring close to control cables.
Cable length must be such that connectors are accessible for
repair.
The wiring to the transceiver must be installed such that water
droplets formed by condensation will not run into the connector.
Remove the turning knob in order to install the transceiver:
o Remove the turning knob cap with an appropriate tool.
o Loosen the screw and remove the turning knob.
o Install cap correctly oriented!
Installation is from the front side of the instrument panel with four
4mm screws in a 57mm panel cut-out as indicated in 5.15.2.
For installation details and drawings refer to chapter “5.15.2 Wiring
Diagram
”.
