AirSep AS-E - Manifold Components

AS-D+—AS-P Series Instruction Manual 19
AirSep Corporation
4.4 MANIFOLD COMPONENTS
Figure 4.2 below illustrates the manifold components of the oxygen generator. The
location and the presence of components may vary between the various models of
the generator.
Bed A
Feed Valves Mufers
Particulate Filter
Feed Air Regulator
Coalescing Filter
Filter Drain Valve
Manual Air Inlet
Valve (V-2)
Manual Air Inlet
Valve (V-1)
Waste Valve
Bed B
Equalization
Valve
Check
Valves
Pressure
Transducer
PI-2
Pressure
Transducer
PI-3
Pressure
Transducer
PI-1
Manual Product
Valve (V-3)
Figure 4.2: Manifold Components — AS-L Model
