AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use 18
Figure 5: AirSpeed 1000 Bottom Ports
Note: When the Serial port is not in use it should be sealed with a cap or plug to keep it secured.
3.2.5 Physical Dimensions
AirSpeed 1000 is an outdoor enclosure.
Table 8. AirSpeed 1000 Physical Dimensions
Variant
Dimensions (H x W x D)
Comment
AirSpeed 1000
220 x 220 x 150 mm / 9 x 9 x 6 in.
The dimensions exclude connectors
and protruding screws
Weight
Main Unit
4 Kg / 8.8 Lbs.
Mounting Bracket
(Bracket Base)
1 Kg. / 2.2 Lbs.
3.2.6 Environmental
Note: AirSpeed 1000 is not meant to be used in a Marine environment.
AirSpeed 1000 meets the following environmental requirements:
 IEC 60529
 IEC 60068
 ETSI EN 300-019-2-4 Operational (non-weather protected equipment)
 ETSI EN 300-019-2-1 Storage (weather protected, not temperature controlled locations)
 ETSI EN 300-019-2-2 Transportation (Public Transportation)
 GR-63, Issue 4
