Maintenance
8-4 2021 Classic
Replacement Rivets
Interior Exterior Underbelly
Part Number 330127-05 330127-08 330126-03 330126-04 330034 330038
Rivet Name AD45ABS AD48ABS SSD44SSBS SSD45SSBS AD68ABSLF AD54ABSLF
Head Style Dome Head Dome Head Dome Head Dome Head Large Flange Large Flange
Body
Diameter
(Inches)
0.125 (1/8) 0.125 (1/8) 0.125 (1/8) 0.125 (1/8) 0.187 (3/16) 0.156 (5/32)
Hole Size 0�129-0�133 0�129-0�133 0�129-0�133 0�129-0�133 0�192-0�196 0�160-0�164
Drill Number 30 30 30 30 11 20
Grip Range In
(Inches)
0�251-0�312 0�376-0�500 0�188-0�250 0�251-0�312 0�376-0�500 0�126-0�250
Length Under
Head (Max.
Inches)
0�453 0�640 0�400 0�438 0�690 0�415
Head
Diameter
(Nominal)
0�250 0�250 0�250 0�250 0�625 0�468
Head Height
(Max. Inches)
0�040 0�040 0�040 0�040 0�092 0�075
Typical Sheer
Strength (lb.)*
155 155 520 520 85 225
Typical Tensile
Strength (lb.)*
235 235 600 600 135 350
*Values shown are a guide only and may vary depending upon the application.
Replacement Filters
Range Hood PN – 512210-100
Return Air Grill Filters PN – 382236
Glycol
Alde Glycol (1 Gallon) PN – 360371-301C
Alde Glycol (5 Gallons) PN – 360371-201C
Exterior Care
The following exterior care products are recommended
by Airstream. Read and follow label directions. Exterior
sealant should be checked and resealed once a year.
Walbernize Super Seal (PN - 28433W) - Use
on exterior aluminum of trailer; recommend two
applications a year.
Acryl-R Seam Sealer (PN - 28430W-01 [16 oz can-
Gray]) - Use anywhere a ne bead of Gray sealant is
required.
Acryl-R Seam Sealer (PN - 28430W-04 [16 oz can-
White]) - Use anywhere a ne bead of White sealant is
required.
Acryl-R Seam Sealer (PN - 28430W-06 [16 oz can-
Clear]) - Use anywhere a ne bead of Clear sealant is
required.
AdSeal Premium Quality Sealant Adhesive
(PN - 365330-01 [10 oz tube-White]) - Use anywhere
a thicker bead of White sealant is required.
AdSeal Premium Quality Sealant Adhesive
(PN - 365330-03 [10 oz tube-Gray]) - Use anywhere a
thicker bead of Gray sealant is required.
AdSeal Premium Quality Sealant Adhesive
(PN - 365330-04 [10 oz tube-Black]) - Use anywhere
a thicker bead of Black sealant is required.
