8. MISCELLANEOUS DRYER DATA
Capacity Correction Factory
All dryer ratings shown are at 100ºF inlet temperature,
100ºF ambient temperature, 100 PSIG inlet pressure. To
correct for different conditions, use Table A, B, C, and D.
Correction Formula:
New Capacity SCFM = (Cat. Rating SCFM) x (A) x (B) x (C) x
(D)
Example: What is the new rating for a Model 3000 at:
(A) Operating PSI of 100 PSIG
(B) Ambient Temperature of 90ºF.
(C) Inlet air temperature of 110ºF. and
(D) Dew point of 35 - 39ºF
Answer:
(SCFM) = 3000 x (1) x (1.05) x (.83) x 1 = 2614.5 SCFM
C
Temp. ºF 80 90 100 110 120
Factor 1.5 1.22 1 .83 .69
Inlet Air Temperature Correction
PSI 50 75 100 125 150
Factor 0.8 0.9 1 1.02 1.05
D
B
A
Temp. ºF 90 100 110 --- ----
Factor 1.05 1 0.9 --- ---
Dew Point 35ºF - 39ºF 42ºF - 45ºF 50ºF
Factor 1 1.10 1.25
Ambient Air Temperature Correction
Inlet Air Pressure Correction
Dew Point Correction Factors
