9. Dryer Information Charts
* Approximate running amps 460 volt / 3 ph = 2.0 amps. x HP
* Approximate running amps 230 volt / 3 ph = 4.0 amps x HP. For exact RL amps check name plate
* Approximate locked rotor amps = 4 to 6 times running amps.
* Water Cooled Units - Max Water PSI = 105 PSI
Min Water PSI = 25 PSI
Max Water Temperature = 85ºF
NOTE: (1) “M/C” amps is minimum circuit ampacity value developed by UL, this value has a calculated safety value and
may be used for wire sizing.
* Pressures referenced in this section refer to units using R-22. For other refrigerants, please refer to service
tag for specifications.
NOTE: If you own a watercooled unit, the second last character in your model number will be a “W” (ie: SC/CT
1000-W4)
SC/CT 40 0.33 7.1 115/1 6.8 20 20 3750 275 3 oz.
SC/CT 60 0.5 9.5 115/1 13.5 20 20 7500 350 3 oz.
SC/CT 80 0.5 9.9 115/1 13.5 20 20 7500 350 3 oz.
SC/CT 100 0.75 13.8 115/1 19.5 30 30 11250 800 3 oz.
SC/CT 130 0.75 14.0 115/1 19.6 30 30 11250 800 3 oz.
SC/CT 165 0.75 14.3 115/1 19.6 30 30 11250 800 3 oz.
SC/CT 220-A2 1 7.3 230/1 8.7 20 15 15000 1050 3 oz.
SC/CT 220-A4 1.5 3.8 460/3 6 15 15 22500 1125 3 oz.
SC/CT 250-A2 1.5 10.36 230/1 15.9 20 15 22500 1125 3 oz.
SC/CT 250-A4 1.5 3.9 460/3 6 20 15 22500 1125 3 oz.
SC/CT 330-A2 1.5 10.36 230/1 15.9 20 20 22500 1125 8 oz.
SC/CT 330-A4 1.5 3.3 460/3 6 15 15 22500 1125 8 oz.
SC/CT 400-A2 2 13.4 230/1 19.1 30 30 30000 2000 15 oz.
SC/CT 400-A3 2 8.48 230/3 13.2 20 20 300000 2000 15 oz.
SC/CT 400-A4 2 4.24 460/3 6.8 15 15 300000 2000 15 oz.
SC/CT 500-A3 3 13.4 230/3 23.7 30 30 45000 2300 15 oz.
SC/CT 500-A4 3 6.7 460/3 11.6 20 20 45000 2300 15 oz.
SC/CT 650-A3 3 13.4 230/3 23.7 30 30 45000 2300 15 oz.
SC/CT 650-A4 3 6.7 460/3 11.6 20 20 45000 2300 15 oz.
SC/CT 800-A3 4 17.9 230/3 25.9 30 30 60000 4200 18 oz.
SC/CT 800-A4 4 10.6 460/3 13.2 30 30 60000 4200 18 oz.
SC/CT 1000-A4 5 9.6 460/3 14.4 20 20 75000 5000 24 oz.
SC/CT 1200-A4 5 9.8 460/3 14.4 20 20 75000 5000 24 oz.
SC/CT 1500-A4 7.5 16.1 460/3 20.1 30 30 112500 5600 30 oz.
SC/CT 2000-A4 10 19.1 460/3 20.1 30 40 150000 5850 45 oz.
SC/CT 2500-A4 15 23.9 460/3 38.4 40 60 225000 12900 45 oz.
SC/CT 3000-A4 15 24.1 460/3 38.4 40 60 225000 12900 69 oz.
(1) Max Heat
Ref. Volt “MC” Max Circuit Reject Fan Additional
Model No. HP FLA PH Amps Fuse Breaker BTU/HR CFM Oil Change
