RC TRANSMITTER CONTROLS
(AIRTRONICS VANGUARD)
1. Telescopic Transmitter Aerial.
2. Transmitter Battery Voltage Meter (Expand Scale Voltmeter)
3. Right Control Stick- Does not operate a function
4,5 Do not operate a function.
6. Left and Right Turns Trim Lever (Unused-disabled). Normal=center.
7. Power Switch - Turns Transmitter on and off.
8. Left/Right Trim Lever for left control stick (Unused-disabled). Normal=Center.
9. Left Control Stick- Left and right movement moves the Bear’s head. Forward and
back movement of the stick does not control a function.
10. Neck Strap Connecting Hook.
11. Switch - Left eyelid movement, open and close.
12. Switch - Right eyelid movement, open and close.
13. Switch - Eyes movement, left and right.
14-17 Do not operate a function
18. Switch (Function up - Center off - Function down-momentary.)
All Robots
Up - Cassette Player
Down - Siren (All Robots Except School Bus.)
• The switches that are listed 'Does not operate a function', are used for other types of
robots.
