Airwell AWSI-HKD018-N11 User Manual

Exploded View and Spare Part list
Indoor Units 17
Spare part list of indoor unit: AWSI-HKD009-N11
No.
Part Name
Qty
BOM Code
No.
Part Name
Qty
BOM Code
1
Panel assembly
1
2011325A5387
16.1
Louver motor
1
202400200031
3
Display box assembly
1
2033325A2367
17
Pipe clamp board
1
201119900949
3.1
Display board
assembly
1
2013330A0831
18
Installation plate
1
201232590037
4
Cover of electrical
equipment
1
201119901024
19
Electronic control box
assembly
1
203332391198
5
Panel frame
assembly
1
201132591041
19.1
Electronic control box
I
1
201132490125
5.1
Screw cap
2
201119900950
19.2
Electronic control box
II
1
201132490150
6
Drain hose
1
201101020038
19.3
Indoor main control
board assembly
1
201332391780
7
Pipe Nut
1
201600320001
19.4
Ambient temperature
sensor assembly
1
202433190000
7
Pipe Nut
1
201600320000
19.5
Pipe temperature
sensor assembly
1
202301300426
8
Fix clamp of
temperature sensor
1
201102000305
19.6
Wire joint
1
202301450119
9
Evaporator assembly
1
201532390220
20
Cover of electronic
control box
1
201132490126
10
Fan motor cover
1
201132490127
21
Remote Controller
1
203355091552
11
Asynchronous motor
1
202400400213
22
Seal ring
1
202720090001
12
Bearing holder
1
201119900952
23
Drain joint
1
201101020011
13
Bearing base
1
202719900606
24
Anti-bacterial filter
1
201131410703
14
Cross flow fan
1
201100200306
25
Air filter(left)
1
201132591042
15
Horizontal louver
1
201132591044
26
Air filter(right)
1
201132591040
16
Chassis assembly
1
201132591057
Nano photocatalysis
filter
1
201130100273
