Airwell AWSI-HKD018-N11 User Manual

Exploded View and Spare Part list
32 Indoor Units
Spare part list of indoor unit: AWSI-HND018-N11
No.
Part Name
Qty
BOM Code
No.
Part Name
Qty
BOM Code
1
Panel assembly
1
2011328A2355
16
Bearing base
1
202719900606
2
Air filter
2
201132890670
17
Cross flow fan
1
201100200056
3
Display box assembly
1
2033327A0877
18
Chassis assembly
1
201132890703
3.1
Display board
assembly
1
2013330A0830
19
Pipe clamp board
1
201232800103
4
Cover of electrical
equipment
1
201133091048
20
Installation plate
1
201232590038
5
Panel frame
assembly
1
201132890673
21
Electronic control box
assembly
1
2033328A0969
5.1
Screw cap
3
201119900950
21.1
Wire joint
1
202301450120
6
Horizontal louver
1
201132890671
21.1
Wire joint
1
202301450119
7
Air outlet assembly
1
2011328A1649
21.2
Electronic control box
1
201133090976
7.1
Louver motor
1
202400200120
21.3
Indoor main control
board assembly
1
2013328A0727
8
Drain hose
1
201101020038
21.5
Ambient temperature
sensor assembly
1
202432390005
9
Pipe nut
1
201600320000
21.6
Pipe temperature
sensor assembly
1
202301300584
9
Pipe nut
1
201600320002
21.7
Cover of electronic
control box
1
201133090981
10
Fix clamp of
temperature sensor
1
201102000305
23
Remote Controller
1
203355091552
11
Evaporator assembly
1
201532890153
24
Seal ring
1
202720090001
12
Fan motor cover
1
201133090980
25
Drain joint
1
201101020011
13
Fixing board of fan
motor
1
201133090167
26
Anti-bacterial filter
1
201131410703
14
Brushless DC Motor
1
202400300064
Nano photocatalysis
filter
1
201130100273
15
Bearing holder
1
201119900952
ESF
1
202319900113
