Dimensions
Light Commercial 41
Model
Outline dimension(mm)
Air outlet opening size
Air return opening size
Size of outline dimension
mounted plug
A
B
C
D
E
F
G
H
I
J
K
L
M
AWSI-DCD012-N11
700
210
635
570
65
493
35
119
595
200
80
740
350
2.3 Console
